Optical Encoder iCs

The Optical Encoder iCs utilize active photodiode arrays for incremental and absolute optical encoders.

The Optical Encoder portfolio ranges from simple photodiode arrays up to highly integrated System-On-Chip iCs, combining into one chip: opto sensors, signal conditioning and processing circuits, interpolation, parallel or serial interfaces, multiturn interfaces, controlled LED driver and other functions.

Standard code discs and reticles (when necessary) are also available for different resolution and size possibilities. Phased-Array technology products are also available, which do not require reticles on the chip.

Applications:

Motion control (position and speed)
Drive systems
Robotics
Optical encoders

iC-Haus Optical Encoder iCs:

iC-LGC	21-Bit Optical Position Encoder with Serial/Parallel and Sin/Cos Output - BiSS-C Key Features: Small-outline optoBGA or BLCC package for SMT System-on-chip design with integrated photosensors Differential scanning for EMI immunity and operation up to 125 °C Enlarged assembly tolerance due to pre-positioned and post-positioned code scanning 13 digital tracks + 2 sine/cosine tracks with analog signal conditioning Singleturn resolution of 16 to 21 bits by 3-bit flash or 8-bit S&H ADC Interface for external multiturn data processing, embedded low power counter for battery supply LED power control with a 50 mA highside driver 4 to 5.5 V single supply operation Temperature sensor with alarm CRC protected data with life counter Applications: Absolute position encoders for safety-related controls Analog and digital motor feedback systems Robotics, tooling machines, servo drives Download iC-LGC technical documentation Download material about iC-LGC Evaluation Kits and Tools BiSS-C Protocol Description (Chinese) More information about iC-LGC (iC-Haus website in English)
iC-LNB	18-Bit Optical Encoder with SPI and Serial/Parallel and FlexCount® Outputs Key Features: System-on-chip design for excellent reliability Leading/trailing sampling of 10 binary tracks pitched at 400 μm Analog sine/cosine scanning with enlarged photodiodes, signal conditioning and fast 8-bit vector tracking interpolation Absolute singleturn resolution of up to 18 bit Diff. sine/cosine outputs with 1024 CPR (amplitude: 500 mV) Unique FlexCount® circuit: freely selectable resolution for absolute and incremental data Incremental quadrature outputs with 1 to 65,536 CPR and programmable index signal LED illumination with automatic control by 50 mA high-side current source Alarm indication for configuration or illumination error (end of life) 3.3 V-compatible SPI and I/O ports for configuration and data Serial data readout in 1 μs cycles at 16 MHz clock frequency Parallel position data output for 16 bit Applications: Optical position sensors Linear scales Absolute, incremental and parallel encoders Programmable incremental encoders Motor feedback systems Download iC-LNB technical documentation Download material about iC-LNB Evaluation Kits and Tools Download iC-LNB Software Download iC-LNB optical code disks documentation More information about iC-LNB (iC-Haus website in English)
iC-LNG	16-Bit Optical Encoder with SPI and Serial/Parallel Outputs Key Features: System-on-chip design for excellent reliability Gray code scanning (11 digital tracks pitched at 400 μm) Sine/cosine analog track with electronic calibration Diff. sine/cosine outputs with 1024 CPR (amplitude: 500 mV) Absolute position value of up to 16 bits through 6-bit interpolation Quadrature signals with 1024, 2048, 4096, 8192, 16384 CPR Index signal in phase with B low LED illumination with automatic control by 50 mA high-side current source Alarm indication for configuration or illumination error (end of life) 3.3 V-compatible SPI and I/O ports for configuration and data Serial data readout in 1 μs cycles at 16 MHz clock frequency Parallel position data output for 14 bit Applications: Optical position sensors Linear scales Absolute, incremental and parallel encoders Programmable incremental encoders Motor feedback systems Download iC-LNG technical documentation Download material about iC-LNG Evaluation Kits and Tools Download iC-LNG Software Download iC-LNG optical code disks documentation More information about iC-LNG (iC-Haus website in English)
iC-LSC	12-Channel Active Photosensor Array Key Features: Monolithic array of independent photosensors with excellent matching Compact photosensor size of 800μm x 300μm enabling high-quality encoder scanning at reduced system dimensions Narrow track pitch of 0.42mm cuts down illumination efforts Enhanced EMI immunity due to on-chip pre-amplification Dark current compensation permits high temperature operation Open-collector outputs as highside current source Simple gain setting and current-to-voltage conversion by external load resistors Applications: Optical position encoding from analog sine/cosine signals Incremental encoders with index signal Motor commutation encoders Download iC-LSC technical documentation More information about iC-LSC (iC-Haus website in English)
iC-LSHB	Incremental Photosensor Array Key Features: Monolithic array of independent photosensors with excellent matching Compact photosensor size of 800μm x 330μm enabling smaller encoder systems Moderate track pitch for reasonable alignment tolerances On-chip low noise amplifiers Ultra low dark currents for operation to high temperature Short-circuit-proof, low impedance voltage outputs for enhanced EMI tolerance Applications: Incremental rotary encoders Linear scales Download iC-LSHB technical documentation Download material about iC-LSHB Evaluation Kits and Tools Download iC-LSHB optical code disks documentation More information about iC-LSHB (iC-Haus website in English)
iC-LSHC	3-Channel Sin/Cos Photosensor Array Key Features: Monolithic array of independent photosensors with excellent matching Compact photosensor size of 800μm x 330μm enabling smaller encoder systems Moderate track pitch for reasonable alignment tolerances On-chip low noise amplifiers Ultra low dark currents for operation to high temperature Short-circuit-proof, low impedance voltage outputs for enhanced EMI tolerance Applications: Optical position encoding from analog sine/cosine signals Incremental encoders with interpolation Absolute position encoders using nonius scales Download iC-PN/iC-LSHC Flyer (Chinese) Download iC-LSHC technical documentation Download iC-LSHC optical code disks documentation More information about iC-LSHC (iC-Haus website in English)
iC-LTA	6-Channel Incremental Opto Encoder Key Features: Monolithic photodiode array with excellent signal matching Very compact size for small encoders Moderate track pitch for relaxed assembly tolerances Low noise signal amplifiers with high EMI tolerance Single-pin programming of 3 operating modes: analog, digital, and x2 interpolated Analog signals for alignment and resolution enhancement Selectable index gating: 1 T, 0.5 T (B-gated), 0.25 T (AB-gated) Complementary outputs: A, B, Z and NA, NB, NZ High output frequency for speedy drives and high resolution U, V,W commutation signals, analog and digital All outputs +/- 4mA push-pull, current-limited and short-circuit-proof LED power control with 40mA high-side driver Single 3.5 V to 5.5V operation, low power consumption Applications: Incremental encoder BLDC motor commutation Industrial drives Download iC-LTA technical documentation Download material about iC-LTA Evaluation Kits and Tools Download iC-LTA optical code disks documentation More information about iC-LTA (iC-Haus website in English)
iC-LV	5-Bit Optical Encoder with Cascadable Serial Interface (SSI) Key Features: High synchronism and technical reliability due to monolithic construction featuring on-chip photosensors Scanning with constant-light evaluation at a pitch of 600 µm Photocurrent amplifiers with high cut-off frequency Adjustable illumination control with 40 mA LED driver ensures constant receiver power over life Monitoring of safe operating range with alarm message (eg. EOL message on LED control error) Serial data output via extended SSI interface Parallel 5 bit data output as Gray or binary code Adjustable phase of MSB track selects for sense of Gray code direction Selectable all-track bit inversion Supports chain circuits of multiple devices including synchronisation options Applications: Scanning with constant-light evaluation for optical encoders Low-res singleturn encoders Multiturn encoders Download iC-LV technical documentation More information about iC-LV (iC-Haus website in English)
iC-OF	3-Bit Optical Encoder Key Features: Monolithically integrated photodiodes (half-track pitch 300 µm) Excellent matching and reliability Elimination of dark current effects through differential scanning Comparators with precise photocurrent-related hysteresis Short-circuit-proof CMOS-/LSTTL-compatible outputs Additional analog push-pull outputs Applications: Optical position decoding for incremental encoders using the principle of differential scanning Download iC-OF technical documentation More information about iC-OF (iC-Haus website in English)
iC-OG	8-Bit Differential Scanning Optical Encoder with LED Control Key Features: Excellent matching and reliability Differential scanning eliminates dark current effects (half-track width: 300 µm) Comparators with precise photocurrent related hysteresis Short-circuit-proof, CMOS-/LSTTL-compatible outputs Additional analog push-pull outputs Adjustable 80 mA LED current control for constant photosensor currents Control monitoring with alarm output Applications: Optical position decoding using the principle of differential scanning Incremental and absolute encoders with a resolution of up to 8 bits Download iC-OG technical documentation More information about iC-OG (iC-Haus website in English)
iC-PD3948	5-Channel Phased Array Sine Encoder (diameter 39 mm, 2048 PPR) Key Features: Compact, 5-channel optical encoder with differential scanning and analog sine/cosine outputs: 2048 CPR with index, 1 CPR absolute, size ∅ 39 mm Blue-ready and IR capable high-definition phased array design for excellent signal matching Reduced cross talk due to moderate track pitch Ultra low dark currents for operation up to high temperature Low-noise amplifiers with high transimpedance gain Short-circuit-proof, low impedance voltage outputs for enhanced EMI tolerance Low power consumption from single 4.1 to 5.5 V supply Operational temperature range of -40 to +125 °C Applications: Incremental sine encoders with commutation information Motor feedback AC and BLDC motor systems Download iC-PD3948 technical documentation Download material about iC-PD3948 Evaluation Kits and Tools Download iC-PD3948 optical code disks documentation More information about iC-PD3948 (iC-Haus website in English)
iC-PG	Miniature Reflective Optical Absolute Encoder Key Features: Lensless reflective opto-encoder iCs, compact, absolute Suitable reflective code discs of ∅ 8 mm Monolithic PD Array with excellent signal matching Integrated blue LED, EncoderBlue® Low-noise signal amplifiers with high EMI tolerance 5-bit Gray code with 30 positions 2 positions reserved for PowerOn/Error indication Push-Button function, analog output: 0.5 to 4.5 V with 64 steps Gray output: Push-Pull Driver, with 1.6 mA Operating Temperature -40 to +105 °C Low power consumption from single 4.5 to 5.5 V supply Compact and lensless optoDFN mold package Applications: Absolute encoders Car AV equipment Human-machine interface Rotary control knob Download iC-PG Flyer (Chinese) Download World of Mini Encoder iCs Flyer (Chinese) Download Optical Reflective Encoder iCs cleaning instructions (Chinese) Download iC-PG technical documentation Download material about iC-PG Evaluation Kits and Tools Download iC-PG optical code disks documentation More information about iC-PG (iC-Haus website in English)
iC-PN Series	Phased Array Nonius Encoder Key Features: Compact, high resolution absolute encoder Monolithic 3-channel HD Phased Array with excellent signal matching Moderate track pitch for reduced cross talk Ultra low dark currents for operation up to high temperature Low noise amplifiers with high transimpedance gain Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs Space saving optoQFN and optoBGA packages (RoHS compliant) Applications: Absolute position encoders AC servo feedback Variants: iC-PN18xx Series (Optical radius 6.9 mm, code disc ∅ 18.0 mm, 64 CPR to 256 CPR) iC-PN26xx Series (Optical radius 10.9 mm, code disc ∅ 26.0 mm, 256 CPR to 1024 CPR) iC-PN33xx Series (Optical radius 14.5 mm, code disc ∅ 33.0 mm, 256 CPR) iC-PN39xx Series (Optical radius 17.5 mm, code disc ∅ 39.0 mm, 1024 CPR) Download iC-PN/iC-LSHC Flyer (Chinese) Download iC-PN Series technical documentation Download material about iC-PN Series Evaluation Kits and Tools More information about iC-PN Series (iC-Haus website in English)
iC-PNE Series	Octal Nonius Phased Array Encoders - (preliminary) Key Features: For compact, high resolution absolute position encoders Monolithic 3-channel HD phased array with excellent signal matching Embedded octal sector detection by 4-bit Gray code scanning Moderate track pitch for reduced crosstalk Ultra-low dark currents for operation at high temperatures Low-noise photocurrent amplifiers with 1 MΩ transimpedance gain Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs Operation from 4.1 V up, respectively 1.8 V for digital section Operational temperature range of -40 to +125 °C Space-saving, RoHS compliant optoQFN package Download iC-PNE Series Flyer (Chinese) Download iC-PNE Series technical documentation Download iC-PNE Series optical code disks documentation More information about iC-PNE Series (iC-Haus website in English)
iC-PNH Series	Phased Array Nonius Encoder Key Features: Compact, high resolution absolute encoder IC for up to 24 bit singleturn resolution (with nonius interpolation) For code disc of ∅26mm, ∅33mm, ∅39mm Monolithic 3-channel HD Phased Array with excellent signal matching Moderate track pitch for reduced cross talk Ultra low dark currents for operation to high temperature Low noise amplifiers with high transimpedance gain Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs Embedded sector detection by 2 digital tracks (2-bit Gray code) Applications: Absolute position encoders AC servo feedback Download iC-PNH Series Flyer (Chinese) Download iC-PNH Series technical documentation Download material about iC-PNH Series Evaluation Kits and Tools Download iC-PNH Series optical code disks documentation More information about iC-PNH Series (iC-Haus website in English)
iC-PR Series	EncoderBlue® Reflective Optical Encoders Key Features: Lensless, reflective opto-encoder iCs, compact, high-resolution, incremental Suitable reflective code discs of ∅4, ∅14, ∅26 and ∅43mm and linear scales with 256 μm period length Monolithic HD Phased Array with excellent signal matching Integrated blue LED with power control, EncoderBlue® Low-noise signal amplifiers with high EMI tolerance Pin-selectable modes of operation: Digital A/B/Z (x1, x2, x4, x8, x16 interpolated), analog COS/SIN with analog or digital Z Pin-selectable index gating: Ungated (1 T), B-gated (0.5 T), AB-gated (0.25 T) Pin-selectable minimal edge distance: 80 ns, 1 μs, 10 μs Analog signal output for ease of alignment and resolution enhancement by external interpolation Operating temperature range of -40 °C to +105 °C Applications: Incremental encoders Miniature motors and actuators X-Y and linear stages Factory automation robots Consumer robots Download iC-PR Series Flyer (Chinese) Download World of Mini Encoder iCs Flyer (Chinese) Download Optical Reflective Encoder iCs cleaning instructions (Chinese) Download the whitepaper "Encoder Blue goes reflective" (Chinese) Download iC-PR Series technical documentation Download material about iC-PR Series Evaluation Kits and Tools Download iC-PR Series optical code disks documentation More information about iC-PR Series (iC-Haus website in English)
iC-PT Series	6-Channel Phased Array Opto Encoder IC Series Key Features: Monolithic photodiode array with excellent signal matching Very compact size for small encoders Moderate track pitch for relaxed assembly tolerances Low noise signal amplifiers with high EMI tolerance Single-pin programming of 3 operating modes: analog, digital, and x2 interpolated Analog signals for alignment and resolution enhancement Selectable index gating: 1 T, 0.5 T (B-gated), 0.25 T (AB-gated) Complementary outputs: A, B, Z and NA, NB, NZ Up to 40,000 RPM at 1250 CPR (20,000 RPM at 2500 CPR) U, V,W commutation signals, analog and digital All outputs +/- 4mA push-pull, current-limited and short-circuit-proof LED power control with 40mA high-side driver Single 3.5 V to 5.5V operation, low power consumption Applications: Incremental encoder BLDC motor commutation Industrial drives Download iC-PT Series technical documentation Download iC-PT Series optical code disks documentation More information about iC-PT Series (iC-Haus website in English)
iC-PT H-Series	6-Channel Phased Array Opto Encoder IC Series Key Features: Compact, high resolution incremental encoder ICs with up to 2500 CPR (native) and 10,000 CPR (interpolated) For code discs of Ø 26 mm, Ø 33 mm, and Ø 39 mm Excellent signal matching Moderate track pitch for relaxed assembly tolerances Low noise signal amplifiers with high EMI tolerance Pin-selectable operating modes: analog, digital, and interpolated (x2 and x4) Analog signals for alignment and resolution enhancement by external interpolation Pin-selectable index gating: 1 T, 0.5 T (B-gated), 0.25 T (AB-gated) Complementary outputs up to 1.6 MHz: A, B, Z and NA, NB, NZ Commutation signals output: U, V, W All outputs +/- 4mA push-pull, current-limited and short-circuit-proof LED power control with 40mA high-side driver Single 3.5 V to 5.5V operation, low power consumption Applications: Incremental encoder BLDC motor commutation Industrial drives Download iC-PT H-Series technical documentation Download material about iC-PT H-Series Evaluation Kits and Tools Download iC-PT H-Series optical code disks documentation More information about iC-PT H-Series (iC-Haus website in English)
iC-PX Series	Reflective Opto Encoders Key Features: Lensless, reflective opto-encoder iCs, compact, high-resolution, incremental Suitable reflective code discs of ∅26 and ∅32 mm Monolithic HD Phased Array with excellent signal matching Integrated blue LED, EncoderBlue® LED power control with 20 mA driver Low-noise signal amplifiers with high EMI tolerance Pin-selectable modes of operation: Digital A/B (x1, x2, x4, x8, x16 interpolated) Short-circuit-proof, current-limited, +/- 4 mA push-pull outputs Compact and lensless optoDFN mold package Operating temperature range of -40 °C to +105 °C Applications: Incremental encoders Miniature motors and actuators X-Y and linear stages Factory automation robots Consumer robots Download iC-PX Flyer (Chinese) Download World of Mini Encoder iCs Flyer (Chinese) Download Optical Reflective Encoder iCs cleaning instructions (Chinese) Download the whitepaper "Encoder Blue goes reflective" (Chinese) Download iC-PX Series technical documentation Download material about iC-PX Series Evaluation Kits and Tools Download iC-PX Series optical code disks documentation More information about iC-PX Series (iC-Haus website in English)
iC-PXL3212	Optical Reflective 2-Channel Digital/Analog Encoder Key Features: Lensless reflective opto-encoder iCs, compact, high-resolution, incremental For reflective discs of >Ø10mm and linear scales Monolithic HD Phased Array with excellent signal matching Integrated blue LED with power control, EncoderBlue® Low-noise signal amplifiers with high EMI tolerance Pin-selectable modes of operation: Digital A/B(×16,×64 interpolated) or analog sin/cos OTP FlexCount® Analog signal output for ease of alignment and resolution enhancement by external interpolation Operating temperature range of –40°C to +125°C Compact and lensless optoQFN mold package (4mm×4mm×0.9mm) Evaluation kits available Applications: Lidar Encoder Robotics E-Motor Medical Download iC-PXL3212 Flyer (Chinese) Download Optical Reflective Encoder iCs cleaning instructions (Chinese) Download the whitepaper "Encoder Blue goes reflective" (Chinese) Download iC-PXL3212 technical documentation More information about iC-PXL3212 (iC-Haus website in English)
iC-PZ Series	High-Resolution Optical Reflective Absolute Encoder Key Features: Reflective, compact, high-resolution, absolute encoder iC iC-PZ2656 for reflective code discs (ø26 mm) and iC-PZ205 for linear scales (max. 6.71m) Miniature oQFN32 5×5 package Monolithic HD Phased Array with excellent signal matching System-on-chip design with embedded blue LED for excellent reliability, EncoderBlue® FlexCount® interpolation for arbitrary ABZ resolution UVW commutation signals with 1 to 32 CPR, for motors of up to 32 pole pairs LED power control for constant illumination (sine square or sum control) Absolute singleturn resolution of 22 bits (ø26 mm) via built-in interpolation On-chip automatic signal adjustment Calibration and configuration storage via external I²C EEPROM Digital BiSS, SSI, and SPI interfaces with CMOS I/O Temperature detection and monitoring 2.5, 3.3, and 5.0 V compatible I/O ports Configurable analog outputs Absolute data interface for connection of external multiturn sensors Applications: Linear scales and rotary encoders High accuracy absolute encoders Motion control Download iC-PZ Series Flyer (Chinese) Download World of Mini Encoder iCs Flyer (Chinese) Download Optical Reflective Encoder iCs cleaning instructions (Chinese) Download iC-PZ Series technical documentation Download material about iC-PZ Series Evaluation Kits and Tools Download iC-PZ Series Software Download iC-PZ Series optical code disks documentation BiSS-C Protocol Description (Chinese) More information about iC-PZ Series (iC-Haus website in English)
iC-RZ Series	Optical Twin-Scan Encoder IC with Safety Channel Key Features: Robust and compact EncoderBlue® for a 10-bit PRC disc of Ø 26.5 mm, 42.5 mm Autonomous double-scanning with control (CC) and safety (SC) channels Resolution of 15 bits (CC and SC) using flash interpolators evaluating an incremental track of 1024 CPR Pin-configured control channel (CC) with MT interface (SSI) and serial data output (BiSS) Flexible safety channel (SC) with CRC monitored setup, OEM and user data, signal monitoring, temperature sensing, MT interface (SSI), and serial data output (BiSS, SSI, SPI) Compatible with BiSS Safety protocol Configuration (SC) via interface or external I²C EEPROM Separated channel supplies (5 V) 3.3 V-compatible I/O ports Signal stabilization by on-chip or off-chip LED current control Differential sin/cos signals with 1024 or 2048 CPR Incremental index pulse generation (optional from CC) Operational temperature −40 to +125 °C Applications: Absolute position encoders for functional safety Singleturn and multiturn encoders for motor feedback High-resolution encoders (up to 24 bit using iC-MR3) Download iC-RZ Series Flyer (Chinese) Download iC-RZ Series technical documentation Download material about iC-RZ Series Evaluation Kits and Tools Download iC-RZ Series Software Download iC-RZ Series optical code disks documentation BiSS-C Protocol Description (Chinese) More information about iC-RZ Series (iC-Haus website in English)
iC-WG	14-Bit Differential Scanning Optical Encoder IC Key Features: Operates from a single 4.5 to 20 V supply Excellent matching, high reliability Differential scanning eliminates dark current effects (half-track width: 300 µm) Comparators with precise photocurrent related hysteresis Short-circuit-proof CMOS-/LSTTL-compatible outputs Adjustable LED-current control for constant photosensor currents Control monitoring with alarm output Applications: Optical position decoding with 14 bits based on the principle of differential scanning Download iC-WG technical documentation Download iC-WG optical code disks documentation More information about iC-WG (iC-Haus website in English)
